THE NEW JOUTA LINE IS NOW READY TO SHIP!
After a 2 year hiatus the now Jouta Blue Line Trikes and Quads are finally back in stock! It was worth the wait. The new Jouta Blue line is still modular but there have been tremendous improvements made. They are all Aluminum now instead of Tensile Steel and are almost much lighter in weight, Also they are indirect steer no instead of direct steer.
The Jouta Quads are 2WD. It is available with either 20 x 1.50″ Tires, or 20 x 4″ Fat Tires
Shipping is $125.00 and is added to the total price in the cart. The Jouta Quad is 75% assembled (in 1 Box). Please call for shipping quotes to AK, HI, Canada or any foreign address.
In Stock
In Stock
FULLY ASSEMBLED
In Stock
Jouta Quad Specs (2WD)
| COMPONENTS | ||||||||||
| Cranks | Derailleurs | Shifters | Cassette | Front hubs | Chain | Rims | Spokes | Tires | Brakes | Brake Levers |
| 46T Alloy 170 mm Crankarms | Shimano Altus | Shimano Revoshifter | Shimano Mega Range 11-34 7spd |
Custom CNC Alloy Disc Hubs | KMC | Single Wall Alloy | SS 14g | Kenda Kwick 100PSI | Novich Disc Brakes (2) |
Promax w/ Lock |
| DIMENSIONS | EXTRAS | |||||||||
| Track | Width | Wheelbase | Average Length (Varies) | Seat angle | Seat Height | Weight | Rider weight limit | Gear Inches | X-Seam Range |
Safety Flag, Alloy Pedals |
| 31.5" (80cm) | 33.8" (85.82cm) | 36.3" (92 cm) | 72 3” (1850mm) |
38-45 degrees | 16" | 49 LBS (22.2KG) | 350 Lbs | 24.2" to 58.7" | 34 1/4" to 45 3/8" | INCLUDED |
Jouta Fat Quad Enviolo Specs (2WD)
| COMPONENTS | ||||||||||
| Cranks | Derailleurs | Shifters | Cassette | Front hubs | Chain | Rims | Spokes | Tires | Brakes | Brake Levers |
| 46T Alloy 170 mm Crankarms | Shimano Altus (Used as Tensioner) | Enviolo Shifter | NA | Custom CNC Alloy Disc Hubs | KMC | Single Wall Alloy | SS 14g | Kenda 20x 4 | Novich Disc Brakes (2) |
Promax w/ Lock |
| DIMENSIONS | EXTRAS | |||||||||
| Track | Width | Wheelbase | Average Length (Varies) | Seat angle | Seat Height | Weight | Rider weight limit | Gear Inches | X-Seam Range |
Safety Flag, Alloy Pedals |
| 31.5" (80cm) | 34.5" (87.63cm) | 36.3" (92 cm) | 72 3” (1850mm) |
38-45 degrees | 16" | 55 LBS (24.9KG) | 350 Lbs | 24.2" to 58.7" | 34 1/4" to 45 3/8" | INCLUDED |
